Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Progress photograph showing first guniting on Arch 54. Arch 55 ready for guniting to elevation 7235, and forms nearly complete for first pour in west sluice pipe extension Arch 53.
Type: Visual Materials(Opens in new tab)
Date: 4/10/1942
Call number: photCL SCE 02 - 24722
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
