Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Extrados of Arch No. 55. Gunited below elevation 7235 during April 1942.
Type: Visual Materials(Opens in new tab)
Date: 5/5/1942
Call number: photCL SCE 02 - 24194
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
