Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Close-up of original surface of arch underneath gunite near crown of Arch #20. Note black surface of original Intertol waterproofing. White area in center of Intertol surface chipped down to sound concrete. Disintegrated layer is approximately 1/4" in depth.
Type
Visual Materials(Opens in new tab)
Date
3/26/1942
Call number
photCL SCE 02 - 24135
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
