Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - View of the lower portion of Arch #20 showing area gunited in 1929 with the location of two inspection holes chipped through the gunite. .
Type: Visual Materials(Opens in new tab)
Date: 3/25/1942
Call number: photCL SCE 02 - 24137
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
