Dam 1 second view of leak intakes near station 5-66 elevation 6904

Description
Dam 1 second view of leak intakes near station 5-66 elevation 6904. For Page 3 of Stone & Webster Report.
Type
Visual Materials(Opens in new tab)
Date
1/20/1939
Call number
photCL SCE 02 - 21846a
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)

You might also be interested in

  • Dam 1. Area near station 5-66, elevation 6904 Chipping in progress

    Dam 1. Area near station 5-66, elevation 6904 Chipping in progress

    Visual Materials

    Dam 1. Area near station 5-66, elevation 6904 Chipping in progress. Note 2 holes from which air escaped when applied to 4" drain through downstream backfill. For Page 3 of Stone & Webster Report.

    photCL SCE 02 - 21846c

  • Big Creek, Huntington Lake Dams

    Big Creek, Huntington Lake Dams

    Visual Materials

    Big Creek, Huntington Lake Dams - Copy of Page 3 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 4. Dam #1 - Badly disintegrated and porous concrete in vertical joint near station 5+66, elevation 690-4, after partial removal. Part of old repair plug in lower left center. 5. Dam #1 - Area near station 5+66, elevation 6904. Chipping in progress. Note two holes from which air escaped when applied to 4" drain through downstream backfill. 6. Dam #1. A second view of leak intakes near station 5+66, elevation 6904'. 7. Dam #1. Area near station 5+66, elevation 6904' after guniting.

    photCL SCE 02 - 21846

  • Dam 1. Badly disintegrated and porous concrete in vertical joint near station 5-66, elevation 6904 after partial removal

    Dam 1. Badly disintegrated and porous concrete in vertical joint near station 5-66, elevation 6904 after partial removal

    Visual Materials

    Dam 1. Badly disintegrated and porous concrete in vertical joint near station 5-66, elevation 6904 after partial removal. Part of old repair plug in lower left center. For Page 3 of Stone & Webster Report.

    photCL SCE 02 - 21846b

  • Dam #1

    Dam #1

    Visual Materials

    Dam #1 - Area near Station 5+66 elevation 6904 after guniting.

    photCL SCE 02 - 23650

  • Big Creek, Huntington Lake Dams - Copy of Page 4 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 8. Dam 1 - East end

    Big Creek, Huntington Lake Dams - Copy of Page 4 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 8. Dam 1 - East end

    Visual Materials

    Big Creek, Huntington Lake Dams - Copy of Page 4 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 8. Dam 1 - East end - Grouting equipment in operation. 9. Dam 2 - Chipped out horizontal construction joint. This bad joint was found after removing old forms near station 13+23, elevation 6919.5' 10. Dam 2 - Chipped out vertical contraction crack near east end. 11. Dam 2 - Guniting chipped out areas.

    photCL SCE 02 - 21847

  • Big Creek, Huntington Lake Dams

    Big Creek, Huntington Lake Dams

    Visual Materials

    Big Creek, Huntington Lake Dams - Copy of Page 7 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 19. Dam 2, station 10+75, view of face at reference station for vertical profile. Note drill holes for determining depth of disintegration. 20. Dam 2. Seam & spalled concrete near station 13+75, elev. 6902' 21. Spalled area at Dam 2 looking east from about station 12+00; reservoir at elevation 6899'. 22. Dam 2, looking east from 14+50. Excavation in foregroundis at about elevation 6901'.

    photCL SCE 02 - 21850
