Dam 1. Badly disintegrated and porous concrete in vertical joint near station 5-66, elevation 6904 after partial removal

Description: Dam 1. Badly disintegrated and porous concrete in vertical joint near station 5-66, elevation 6904 after partial removal. Part of old repair plug in lower left center. For Page 3 of Stone & Webster Report.
Type: Visual Materials(Opens in new tab)
Date: 1/20/1939
Call number: photCL SCE 02 - 21846b
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
