Dam 1. Area near station 5-66, elevation 6904 Chipping in progress

Description
Dam 1. Area near station 5-66, elevation 6904 Chipping in progress. Note 2 holes from which air escaped when applied to 4" drain through downstream backfill. For Page 3 of Stone & Webster Report.
Type
Visual Materials(Opens in new tab)
Date
1/20/1939
Call number
photCL SCE 02 - 21846c
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
