Big Creek, Huntington Lake Dams - Copy of Page 4 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 8. Dam 1 - East end

Description
Big Creek, Huntington Lake Dams - Copy of Page 4 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 8. Dam 1 - East end - Grouting equipment in operation. 9. Dam 2 - Chipped out horizontal construction joint. This bad joint was found after removing old forms near station 13+23, elevation 6919.5' 10. Dam 2 - Chipped out vertical contraction crack near east end. 11. Dam 2 - Guniting chipped out areas.
Type
Visual Materials(Opens in new tab)
Date
1/20/1939
Call number
photCL SCE 02 - 21847
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
