Description
Big Creek, Huntington Lake Dams - Copy of Page 7 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 19. Dam 2, station 10+75, view of face at reference station for vertical profile. Note drill holes for determining depth of disintegration. 20. Dam 2. Seam & spalled concrete near station 13+75, elev. 6902' 21. Spalled area at Dam 2 looking east from about station 12+00; reservoir at elevation 6899'. 22. Dam 2, looking east from 14+50. Excavation in foregroundis at about elevation 6901'.
Type
Visual Materials(Opens in new tab)
Date
1/20/1939
Call number
photCL SCE 02 - 21850
