Visual Materials

Vermilion

Description: Vermilion - 90 degree "V" notch weir installed near lower bridge over service spillway to measure flow from under drain system between spillway and toe of dam near east abutment. Included also is flow from drains under spillway itself.
Type: Visual Materials(Opens in new tab)
Date: Sep. 1956
Call number: photCL SCE 02 - 44796
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
