Visual Materials

Big Creek, Vermilion Dam - V-notch weir just southwest of bridge over service spillway

Description: Big Creek, Vermilion Dam - V-notch weir just southwest of bridge over service spillway - Installed August 18, 1956 - collects all seepage west of service spillway.
Type: Visual Materials(Opens in new tab)
Date: Sep. 1956
Call number: photCL SCE 02 - 44803
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
