Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - View showing timber backing for 14"welded plate diversion bulkhead in 12' diameter pipe.
Type: Visual Materials(Opens in new tab)
Date: 7/23/1955
Call number: photCL SCE 02 - 43307
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
