Portal Powerhouse

Description
Portal Powerhouse - Applying Protex protective coating to first section of 8.5' diameter penstock pipe prior to pulling into 12' diameter pipe for second section make-up.
Type
Visual Materials(Opens in new tab)
Date
8/22/1955
Call number
photCL SCE 02 - 43570
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
