Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - First four sections of 8.5 diameter penstock, ready for install.
Type: Visual Materials(Opens in new tab)
Date: 8/11/1955
Call number: photCL SCE 02 - 43645
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
