Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - View of forms for conctete box at 8" fish pipe, raising elevation of intake and trash rack to clear sand washed down from backfill into center of channel. .
Type
Visual Materials(Opens in new tab)
Date
11/30/1943
Call number
photCL SCE 02 - 24899
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
