Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo showing backfill in river section, sluice gate trash racks and newly completed fish pipe intake at close of 1943 work by construction crew.
Type: Visual Materials(Opens in new tab)
Date: 12/1/1943
Call number: photCL SCE 02 - 24898a
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Record photo showing backfill in river section, sluice gate trash racks and newly completed fish pipe intake at close of 1943 work by construction crew. [variant of 02-24898a].
photCL SCE 02 - 24898b
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of completed extension of 8" fish pipe upstream from Arch 53. This extension was necessary to extend intake of fish pipe through proposed backfill on the upstream side of the river section arches up to elevation 7235. Backfill to be placed during fall of 1942.
photCL SCE 02 - 24720
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of forms for conctete box at 8" fish pipe, raising elevation of intake and trash rack to clear sand washed down from backfill into center of channel. .
photCL SCE 02 - 24899
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Progress photo showing first stages of backfill west side of channel. Building forms for east Sluice Gate extension and Bryant crew applying asbestile plastic on Arch No. 51.
photCL SCE 02 - 24815
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Progress photo taken while erecting trash racks for sluice gates in river section.
photCL SCE 02 - 24867
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Hand placing earth backfill around partially poured east Sluice Gate extension concrete.
photCL SCE 02 - 24823
