Visual Materials

Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo showing backfill in river section, sluice gate trash racks and newly completed fish pipe intake at close of 1943 work by construction crew. [variant of 02-24898a].
Type: Visual Materials(Opens in new tab)
Date: 12/1/1943
Call number: photCL SCE 02 - 24898b
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
