Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - View of downstream side Arch 52, lake elevation 7261.90 after completion of guniting. General dampness along 7252 joint running down two to three lifts in places. General dampness along 7240 lift and below. 7244, 7248, 7256, and 7260 lifts appear to be dry.
Type: Visual Materials(Opens in new tab)
Date: 6/10/1942
Call number: photCL SCE 02 - 24738
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of river section looking N (downstream) from approximately the upstream face of Arch 53, showing heavy reinforcing at junction of Buttresses 53 & 54, with arches 52, 53, & 54 (highest portion of dam), interados form trusses and studding for lower lifts on Arch 54, and counterweighted placing chutes in position for concreting a lift in Buttress 54.
photCL SCE 02 - 12707
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of downstream side of Arch 53, lake elevation 7261.90. Note slight dampness along 7252 joint 5' left to 20' right of centerline, also trace of asbestile waterproofing applied on upstream face duing spring of 1941 showing through joint at elevation 7260 5' left of centerline.
photCL SCE 02 - 24737
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - First guniting above elevation 7235 on Arch 52.
photCL SCE 02 - 24731
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Extrados of Arch No. 52. Taken during guniting operations on this arch. Gunited to elevation 7235 and chipped to elevation 7296.
photCL SCE 02 - 24191
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Progress photo showing chipping on Arch 52 completed to elevation 7264, preparatory to guniting.
photCL SCE 02 - 24719
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. Arch #51 after guniting.
photCL SCE 02 - 22877
