Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Guniting Arch 52 showing location for mixing plant set-up for river section guniting.
Type: Visual Materials(Opens in new tab)
Date: 5/19/1942
Call number: photCL SCE 02 - 24732
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
