Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - Arch #2 Gunite repair preparation Bush hammering surface.
- Date
- 5/17/1940
- Call number
- photCL SCE 02 - 22954
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - Jack hammering surface of arch 7, preparing face for Asbestile coating.
photCL SCE 02 - 23021
Visual Materials
Big Creek, Florence Lake Dam - Surface Arch #28 after smoothing with gunite.
photCL SCE 02 - 25770
Visual Materials
Big Creek, Florence Lake Dam - Close-up of original surface of arch underneath gunite near crown of Arch #20. Original surface chipped free of Intertol. Concrete perfectly sound and dry. .
photCL SCE 02 - 24136
Visual Materials
Big Creek, Florence Lake Dam - Close-up of original surface of arch underneath gunite near crown of Arch #20. Note black surface of original Intertol waterproofing. White area in center of Intertol surface chipped down to sound concrete. Disintegrated layer is approximately 1/4" in depth.
photCL SCE 02 - 24135
Visual Materials
Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. No. 2 of cycle of 7: Chipping out seam. At the moment he is bush-hammering marginal area around the direct key over joint.
photCL SCE 02 - 22880
Visual Materials
Big Creek, Florence Lake Dam - Disintegration of concrete below gunite repair.
photCL SCE 02 - 26669
