Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Looking downstream, from between buttresses, and underside of intrados of arch in river section.
Type: Visual Materials(Opens in new tab)
Date: 10/1/1925
Call number: photCL SCE 02 - 12822
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
