Visual Materials
Making a splice in the aluminum and steel cable during construction of the tower line over Cajon Pass in May of 1912
You might also be interested in
Line crew of 4 CEP workers splicing aluminum steel cable in the desert
Visual Materials
Line crew of 4 CEP workers splicing aluminum steel cable in the desert.
photCL SCE 07 - 00104
One tower of Edison's growing network of 500kV transmission lines stands sentinel in Cajon Pass in the winter of 1973
Visual Materials
One tower of Edison's growing network of 500kV transmission lines stands sentinel in Cajon Pass in the winter of 1973. Pg. 226.
photCL SCE 11 - 00457
Miscellaneous Transmission - New method of splicing 220 kVA aluminum cable
Visual Materials
Miscellaneous Transmission - New method of splicing 220 kVA aluminum cable. - Field splice of aluminum conductor on the Vincent T/L; showing the inner steel sleeve which has been completely compressed over the abutting ends of the stranded steel core forming the interior part of the conductor, and the pouring of a corrosion resistant compound, to be followed by an aluminum wrapping and thereafter the aluminum outer sleeve seen at the right edge of the photo which will be slipped over the splice section and compressed to complete the splice.
photCL SCE 02 - 11539
Stringing wire on the Mira Loma-Lugo 500 kV transmission line in Cajon Pass, 1979
Visual Materials
Stringing wire on the Mira Loma-Lugo 500 kV transmission line in Cajon Pass, 1979. Pg. 222.
photCL SCE 11 - 00446
Preparing to pull through some more cable during the construction of a 500kV transmission line
Visual Materials
Preparing to pull through some more cable during the construction of a 500kV transmission line. Pg. 222.
photCL SCE 11 - 00448
Billy Young (Billy-the-Wind) repairing a blown cylinder head gasket in Cajon Pass, about 1918
Visual Materials
Billy Young (Billy-the-Wind) repairing a blown cylinder head gasket in Cajon Pass, about 1918.
photCL SCE 11 - 00149
