Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Close-up of weir box for measuring flow from the auxiliary drain #1.
Type: Visual Materials(Opens in new tab)
Date: 9/5/1957
Call number: photCL SCE 02 - 44888
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
