Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - Installing temporary 3/8" plate bulkhead at end of turbine branch of penstock inside structure.
Type: Visual Materials(Opens in new tab)
Date: 10/15/1955
Call number: photCL SCE 02 - 43777
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
