Portal Powerhouse

Description: Portal Powerhouse - Installation of penstock supports in pipe. View from downstream side of bulkhead.
Type: Visual Materials(Opens in new tab)
Date: 8/11/1955
Call number: photCL SCE 02 - 43654
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
