Visual Materials

Huntington Lake Dams

Description: Huntington Lake Dams - 6" diameter intake thru steel facing at bottom of access well for fish water release.
Type: Visual Materials(Opens in new tab)
Date: 10/4/1955
Call number: photCL SCE 02 - 43764
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
