Big Creek, Huntington Lake Dams - Upstream Protection

Description
Big Creek, Huntington Lake Dams - Upstream Protection - Drilling 6" outlet hole with Concore drill thru Dam #2, for under drain system in steel facing back.
Type
Visual Materials(Opens in new tab)
Date
9/5/1955
