Big Creek, Huntington Lake Dams
- Description
- Big Creek, Huntington Lake Dams - Placing bottom courses of steel plate facing at Dam #1.
- Date
- 9/4/1955
- Call number
- photCL SCE 02 - 43737
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Huntington Lake Dams - Upstream Protection - Placing first steel facing - Dam #2.
photCL SCE 02 - 43697
Visual Materials
Big Creek, Huntington Lake Dams - Upstream protection - Steel facing being placed in test section at east end of Dam #1. Bottom of section at elvation 6930.
photCL SCE 02 - 43532
Visual Materials
Big Creek, Huntington Lake Dams - First work along bottom of steel facing at elevation 6850. Water approx. elev. 6849.
photCL SCE 02 - 43731
Visual Materials
Big Creek, Huntington Lake Dams - Welding bottom course of steel plate to marginal channel adjacent to 72" sluice gate, west end Dam #1.
photCL SCE 02 - 43678
Visual Materials
Big Creek, Huntington Lake Dams - Gunite protection of marginal cut-off of steel facing area.
photCL SCE 02 - 43743
Visual Materials
Big Creek, Huntington Lake Dams - Upstream Protection - Drilling 6" outlet hole with Concore drill thru Dam #2, for under drain system in steel facing back.
photCL SCE 02 - 43696
