Big Creek, Huntington Lake Dams

Description: Big Creek, Huntington Lake Dams - Welding bottom course of steel plate to marginal channel adjacent to 72" sluice gate, west end Dam #1.
Type: Visual Materials(Opens in new tab)
Date: 8/22/1955
Call number: photCL SCE 02 - 43678
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
