Upstream protection

Description: Upstream protection - View of marginal cut-off in concrete along east slope of Dam #1. Note 6' anchor rods grouted in cut-off to hold marginal channel.
Type: Visual Materials(Opens in new tab)
Date: 8/20/1955
Call number: photCL SCE 02 - 43566
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
