Upstream Protection progress picture at east end of Dam #1. Marginal channel in place along top and extreme east end down to approx. elevation

Description: Upstream Protection progress picture at east end of Dam #1. Marginal channel in place along top and extreme east end down to approx. elevation - 6930.
Type: Visual Materials(Opens in new tab)
Date: 7/25/1955
Call number: photCL SCE 02 - 43319
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
