Big Creek, Huntington Lake Dams - Dam #3

Description: Big Creek, Huntington Lake Dams - Dam #3 - Photograph during a rain shows dry condition of upstream face resulting from construction of concrete eave.
Type: Visual Materials(Opens in new tab)
Date: 12/6/1950
Call number: photCL SCE 02 - 30426
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
