Big Creek, Huntington Lake Dams

Description: Big Creek, Huntington Lake Dams - Copy of Page 11 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 38. General view of chipping and drilling operations. 39. Concreting trench in front of cut off wall. 40. Upstream face of Dam 3A looking north after completion of concreting and guniting. 41. Upstream face looking south after completion of concrete and gunite work.
Type: Visual Materials(Opens in new tab)
Date: 1/20/1939
Call number: photCL SCE 02 - 21854
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
