Big Creek, Huntington Lake Dams - Dam #1

Description: Big Creek, Huntington Lake Dams - Dam #1 - Upstream face gunite; note debris freshly fallen from concrete above ginite. T. M. Leps
Type: Visual Materials(Opens in new tab)
Date: 4/11/1952
Call number: photCL SCE 02 - 40249
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
