Big Creek, Huntington Lake Dams

Description: Big Creek, Huntington Lake Dams - Showing cracked and unanchored area of gunite at Dam #1.
Type: Visual Materials(Opens in new tab)
Date: 3/25/1944
Call number: photCL SCE 02 - 25961
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
