Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - Arches #1, #2, and west part of Arch #3; waterproofing.
- Date
- 6/1/1944
- Call number
- photCL SCE 02 - 25775
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - Record photo of upstream face of Arches 4 to 10 inc. in first tangent. Arch #8 was covered with J-M Asbestile waterproofing during May 1940.
photCL SCE 02 - 24862
Visual Materials
Big Creek, Florence Lake Dam - Record photo of River Section arches. Johns-Manville waterproofing on all arches except Arch No. 53. Upper portion of Arch 53 is covered with Barrett Waterworks enamel. The lower portion is linseed oil treatment over gunite with reflective coating of aluminum.
photCL SCE 02 - 24838
Visual Materials
Big Creek, Florence Lake Dam - Record photo of upstream face of Arches 11 to 25 inclusive in second tangent. Arch #13 covered with sheet steel membrane during June 1942 and Arch #12 covered with J-M Asbestile waterproofing during Nov. 1942.
photCL SCE 02 - 24863
Visual Materials
Big Creek, Florence Lake Dam - Record photo of Arches 57, and 58 after completion of Johns-Manville waterproofing.
photCL SCE 02 - 24837
Visual Materials
Big Creek, Florence Lake Dam - Completed walkway waterproofing Arch #1.
photCL SCE 02 - 24109
Visual Materials
Big Creek, Florence Lake Dam - Record photo of Arches 50, 51, and 52 after completion of Johns-Manville waterproofing.
photCL SCE 02 - 24835
