Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - Removal of old gunite on lower portion of Arch #20.
- Date
- 4/6/1944
- Call number
- photCL SCE 02 - 25763a
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - Removal of old gunite on lower portion of Arch #20. [variant of 02-25763a].
photCL SCE 02 - 25763b
Visual Materials
Big Creek, Florence Lake Dam - View of the lower portion of Arch #20 showing area gunited in 1929 with the location of two inspection holes chipped through the gunite. .
photCL SCE 02 - 24137
Visual Materials
Big Creek, Florence Lake Dam - Old gunite on Arch #20 Extrados.
photCL SCE 02 - 23974
Visual Materials
Big Creek, Florence Lake Dam - Record photo of River Section arches. Johns-Manville waterproofing on all arches except Arch No. 53. Upper portion of Arch 53 is covered with Barrett Waterworks enamel. The lower portion is linseed oil treatment over gunite with reflective coating of aluminum.
photCL SCE 02 - 24838
Visual Materials
Big Creek, Florence Lake Dam - Progress photo showing gunite on Arch 52 and reinforcing mesh in place on the portion of Arch 51 below elevation 7235.
photCL SCE 02 - 24726
Visual Materials
Big Creek, Florence Lake Dam - Close-up of original surface of arch underneath gunite near crown of Arch #20. Original surface chipped free of Intertol. Concrete perfectly sound and dry. .
photCL SCE 02 - 24136
