Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo of downstream side of crib diversion dam while water was down for repairs to intake of fish pipe.
Type: Visual Materials(Opens in new tab)
Date: 12/1/1943
Call number: photCL SCE 02 - 25714
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
