Boulder-Chino Transmission Line (3rd)

Description
Boulder-Chino Transmission Line (3rd) - showing excavation of soil at and between towers 1 to 2 at mile 103. Detail of vertical bank facing north. Material below 1.3' is fine gravel. Material above is clay. Bank about 8.5' high.
Type
Visual Materials(Opens in new tab)
Date
12/11/1947
Call number
photCL SCE 02 - 27893
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
