Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo of upstream face of Arches 50 to 58 inclusive in fifth tangent. All arches except 53 coated with J-M Asbestile waterproofing during Dec. 1942.
Type: Visual Materials(Opens in new tab)
Date: 4/10/1943
Call number: photCL SCE 02 - 24866
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
