Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo of upstream face of Arches 1 & 2 in first tangent. The gunited surface of Arch #2 was covered with a reflecting coat of Mathews "Hi-lite" concrete paint during Dec. 1942.
Type: Visual Materials(Opens in new tab)
Date: 4/10/1943
Call number: photCL SCE 02 - 24861
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
