Big Creek No. 1

Description
Big Creek No. 1 - Rebucketing Unit No. 2 - Close-up showing typical amount of grinding and chipping necessary on front and back of rims for wheel clearance on buckets 10, 22, 44, 46, 47, 48, 52, and 53 (Mfgs' numbers).
Type
Visual Materials(Opens in new tab)
Date
11/24/1943
Call number
photCL SCE 02 - 24847
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
