Visual Materials

Big Creek No. 1

Description: Big Creek No. 1 - Rebucketing Unit No. 2 - Close-up showing counterweight on bucket No.3 which has not been cut to clear rim of wheel.
Type: Visual Materials(Opens in new tab)
Date: 11/24/1943
Call number: photCL SCE 02 - 24846
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
