Big Creek, Huntington Lake Dams

Description
Big Creek, Huntington Lake Dams - Dam 3 showing disintegration elevation 6915'.
Type
Visual Materials(Opens in new tab)
Date
4/3/1942
Call number
photCL SCE 02 - 24569
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
