Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - View of Extrados of Arches 53 & 54.
Type: Visual Materials(Opens in new tab)
Date: 4/5/1939
Call number: photCL SCE 02 - 22162
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
