Showing foundation for 42" pipe extension after pouring 18" mat

Visual Materials

Showing foundation for 42" pipe extension after pouring 18" mat

Description: Showing foundation for 42" pipe extension after pouring 18" mat. Note rock shear keys projecting above concrete.
Type: Visual Materials(Opens in new tab)
Date: 6/19/1937
Call number: photCL SCE 02 - 20146
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
