Dam 1
- Description
- Dam 1. View showing preliminary excavation with bull dozer at upper end of sluice pipe extension.
- Date
- 6/6/1937
- Call number
- photCL SCE 02 - 20135
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Dam 1, View #2 showing excavation at upper end of center 42" pipe extension.
photCL SCE 02 - 20127
Visual Materials
Dam 1, View #1 showing excavation at upper end of center pipe adjacent to concrete block below former location of valves.
photCL SCE 02 - 20126
Visual Materials
Dam 1. Photo #3. Showing cribbing cut through while excavating for foundation under uppper end west 42" sluice pipe extension.
photCL SCE 02 - 20133
Visual Materials
Dam 1. Excavation for east pipe at upper end adjacent to existing concrete block below former location of valves. Hole was filled with concrete before forming 12" bearing walls under pipe extension.
photCL SCE 02 - 20131
Visual Materials
Dam 1. Photo #1 showing cribbing discovered during excavation for West 42" pipe at upper end adjacent to existing concrete.
photCL SCE 02 - 20129
Visual Materials
Dam 1, View showing excavation for 42" pipes at upper end above wye.
photCL SCE 02 - 20128
