Dam 1

Description: Dam 1, View #1 showing excavation at upper end of center pipe adjacent to concrete block below former location of valves.
Type: Visual Materials(Opens in new tab)
Date: 6/12/1937
Call number: photCL SCE 02 - 20126
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
