Visual Materials

Dam 1

Description: Dam 1. Photo #2 Cutting away cribbing found in excavating for foundation under West 42" sluice pipe. At upper end adjacent to existing concrete.
Type: Visual Materials(Opens in new tab)
Date: 6/13/1937
Call number: photCL SCE 02 - 20130
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Dam 1
Visual Materials
Dam 1. Photo #1 showing cribbing discovered during excavation for West 42" pipe at upper end adjacent to existing concrete.
photCL SCE 02 - 20129
Dam 1
Visual Materials
Dam 1. Photo #3. Showing cribbing cut through while excavating for foundation under uppper end west 42" sluice pipe extension.
photCL SCE 02 - 20133
Dam 1. Photo #4
Visual Materials
Dam 1. Photo #4. Close-up view of double row of cribbing cut through while excavating for foundation under west 42" sluice pipe extension.
photCL SCE 02 - 20132
Dam 1
Visual Materials
Dam 1. Excavation for east pipe at upper end adjacent to existing concrete block below former location of valves. Hole was filled with concrete before forming 12" bearing walls under pipe extension.
photCL SCE 02 - 20131
View of excavation for 42" sluice pipe upper end after concrete foundation was poured up to base of 12" bearing wall
Visual Materials
View of excavation for 42" sluice pipe upper end after concrete foundation was poured up to base of 12" bearing wall.
photCL SCE 02 - 20145
Big Creek, Huntington Lake Dams - Dam 1
Visual Materials
Big Creek, Huntington Lake Dams - Dam 1 - Pouring wye section of 42" sluice pipe concrete envelope.
photCL SCE 02 - 25254
