Big Creek, Florence Lake Dam - Upstream face of Dam

Description
Big Creek, Florence Lake Dam - Upstream face of Dam - Showing Arch #53 containing sluice gates. This picture also shows the Arches to the end of the dam, up to and including Arch #58.
Type
Visual Materials(Opens in new tab)
Date
10/3/1928
Call number
photCL SCE 02 - 15913
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
